Molecular Symmetry and Group Theory Workshop 5 — Chemical bonding

• Exercise 6

Use group theory to obtain a qualitative MO energy level diagram for the octahedral complex [CrCl6]3-.

First you will need to consider which Cr3+ orbitals may be used in bonding.

 i) What is the point group?
ii) Using the character table (Click here), determine the symmetry of the orbitals on the central atom to be used in bonding (If a group of orbitals have more than one symmetry, put in alphabetical order separated by ",")
Orbital Symmetry
3d
4s
4p

iii) Select an appropriate basis to obtain a reducible representation. Reducing this will give irreducible representations (i.e. symmetries) for the orbitals in the basis.
It is not strictly necessary to know which orbitals on the Cl- ligands are involved: we can instead use six arrows, one pointing from each Cl- towards the central metal atom, to represent σ-bonding orbitals on the chloride ligands and act as a basis for our reducible representation. Click for larger image Click for larger image

Oh E 8C3 6C2 6C4 3C2i 6S4 8S6 h d
Γ 6

Oh E 8C3 6C2 6C4 3C2i 6S4 8S6 h d
 Order =

Γ 6
A1g 1 1 1 1 11 1 1 1 1
A2g 1 1 -1 -1 1 1 -1 1 1 -1
Eg 2 -1 0 0 2 2 0 -1 2 0
T1g 3 0 -1 1 -1 3 1 0 -1 -1
T2g 3 0 1 -1 -1 3 -1 0 -1 1
A1u 1 1 1 1 1 -1 -1 -1 -1 -1
A2u 1 1 -1 -1 1 -1 1 -1 -1 1
Eu 2 -1 0 0 2 -2 0 1 -2 0
T1u 3 0 -1 1 -1 -3 -1 0 1 1
T2u 3 0 1 -1 -1 -3 1 0 1 -1
N×χR×χI(A1g)
 Σ(N×χR×χI(A1g)) =
 Σ(N×χR×χI(A1g))/Order =
N×χR×χI(A2g)
 Σ(N×χR×χI(A2g)) =
 Σ(N×χR×χI(A2g))/Order =
N×χR×χI(Eg)
 Σ(N×χR×χI(Eg)) =
 Σ(N×χR×χI(Eg))/Order =
N×χR×χI(T1g)
 Σ(N×χR×χI(T1g)) =
 Σ(N×χR×χI(T1g))/Order =
N×χR×χI(T2g)
 Σ(N×χR×χI(T2g)) =
 Σ(N×χR×χI(T2g))/Order =
N×χR×χI(A1u)
 Σ(N×χR×χI(A1u)) =
 Σ(N×χR×χI(A1u))/Order =
N×χR×χI(A2u)
 Σ(N×χR×χI(A2u)) =
 Σ(N×χR×χI(A2u))/Order =
N×χR×χI(Eu)
 Σ(N×χR×χI(Eu)) =
 Σ(N×χR×χI(Eu))/Order =
N×χR×χI(T1u)
 Σ(N×χR×χI(T1u)) =
 Σ(N×χR×χI(T1u))/Order =
N×χR×χI(T2u)
 Σ(N×χR×χI(T2u)) =
 Σ(N×χR×χI(T2u))/Order =

Therefore, the composition of Γ is:
Γ = A1g + A2g + Eg + T1g + T2g + A1u + A2u + Eu + T1u + T2u

Constructing the molecular orbital diagram - All the required information has been determined above (spectroscopic data can be used to assist in determining the relative energies of the bonding molecular orbitals in [CrCl6]3-).
